Tool Room Machines
CMM – ZEISS – Spectrum
Measuring Range
X/Y/Z axis : 700 x 1000 x 600
Excetek Wire EDM – Submerged Model
Specifications
Maximum workpiece (mm) : 850 x 600 x 255 mm 33.5″ x 23.6″ x 10″
Max workpiece weight : 600 kg 1323 lb
Travel of X/Y axes : 500 x 300 mm 19.7″ x 11.8
Travel of UN axes : 120 x 120 mm 4.7″ x 4.7
Travel of Z axis : 260 mm 10.2″
Wire diameter : 0.15-0.3 mm 0.004-0.012″
Number of axes controlled : 5 Axis AC servo motor
Max taper angle : +26°/100 mm ±26°/3.9″ (with wide diamond quide and nozzle)
Mitsubishi – Wire EDM
Machines
Measuring Range
X/Y axis Travel: 600 x 400
STM – Double Column VMC
Measuring Range
X/Y/Z axis Travel: 2200 x 1600 x 1000
Bed Size: 2000 x 1400
Distance between column: 1700
HASS – VMC
Measuring Range
XYZ travels: 1016 mm x 660 mm x 635 mm
Table Size: 1372 x 610 mm
STM – VMC
Measuring Range
X/Y/Z Travel: 2100 x 1600 x 760
Bed Size: 2310 x 1500
Distance between column: 1700
AWEA – Double Column VMC
Measuring Range
X/Y/Z axis Travel: 1600 x 800 x 800
Bed Size: 1800 x 840
Pinnacle & Prayosa – Surface Grinding
Measuring Range
Bed Size: 1000 x 500
STM – VMC
Measuring Range
X/Y/Z axis Travel: 850 x 510 x 510
Bed Size: 1000 x 600
